jrt Posted August 5, 2005 Share Posted August 5, 2005 Interested in buying a V11? See this faq and the 'most common problems' faq This addresses the changes in V11 Sports and LeMans motorcycles from 1999-2005 Thanks and credit goes to the many V11LeMans website contributors. Breakdown of changes in year models from 1999-2005. The V11 sport variants (referred to here as just 'V11') have been produced from about '99 to 2005. I understand that this model is now discontinued, and will no longer be built. That makes it a legacy bike, I guess. Major similarities: All the V11 models are 'spine frame' bikes. The name derives from the large square 'spine' that runs the center of the bike between the cylinders and serves as the main frame component. All the V11 variants have the normal Guzzi two cylinder, two valve/cylinder motor that is in a higher state of tune than the 'cruiser' model Guzzi's. The valves must be adjusted- they are not hydraulic. All the V11 variants have the six-speed transmission and a hydraulic clutch. Older spine frame Guzzi's like the 1100 sport, 1100sporti, etc. have a 5 speed box. Real changes in the bikes from inception to end are small and incremental. 1999-2001 models have a (shorter) red frame than later models. They handle 'quicker' or some say 'more twitchy'. Some say they are unstable at high speed- I've never had a problem. The 99-01 models have clip-ons mounted below the upper triple clamp and have Veglia brand (white face) instruments. They have a thinner rear wheel (4.5") and the brake rotors have circular holes in them; apparently the 'circular hole rotors' are more prone to warping than later rotors. My mid-year '01 has later model rotors fitted, so your guess is as good as mine here. Guzzi went to a longer wheelbase in late '01 or '02 to increase high speed stability. The '01 Rosso Mandello still has the short wheelbase of the 00 V11. Some folks have suggested that appropriate tire choice (Pirelli Diablo) gives a machine that handles like the '00-01 models. '02 and later models have additional bracing in the longer frame and a wider 5.5" rear wheel. New front forks with the clip-ons mounted above the triple clamp are standard. '02 and later models have black engine paint. The '02 model paint is 'fuzzy' and is prone to flaking and blistering off- so it looked horrible- and Guzzi offered new cases to those afflicted with it. New brake rotors (triangular holes) are stock. Late '02 models have commonly been rebadged as '03 models. True '03 models should have a '3' in the VIN and have 'satin' engine paint. Fuzzy engine paint on an '03 model is an indication that it is a rebadged '02 (with short/chin-pad tank, white face instruments and external fuel pump and filter). In '02 or '03, Guzzi changed the electric gas petcock out for a manual version. '03 was a 'big' year for changes in the V11; many improvements were made. Fork diameter is larger (43mm instead of the earlier 40mm), front axle diameter is larger and the axle is hollow. A front crossover or balance pipe is added above the alternator (improves midrange performance ?). The engine has a *claimed* higher compression set of pistons, which are now cooled by an oil jet (more on this below). The fuel pump was relocated to the interior of the gas tank, so '03+ models do not suffer from vapor lock like earlier models (see below). Several cosmetic modifications are present as well- the 'chin pad' is gone in favor of a smooth (longer) tank. The engine paint is satin black, the fairing (if present) mounts further ahead on a different 'gooseneck' mount. Gauges are now ITI/ hUr brand (black faces). This interesting trivia from the V11 board: "I would like to add a note about the speedo on the 02 - 03 V11 Naked. This may or may not be common knowledge. The original and replacement speedos on my bike did exactly the same. The bottom line is that the speedo indicates in MPH, the trip-odometer registers in miles but the odometer registers in 2KM increments. If you don't believe me and have one of these bikes, pull off and stop when the odometer just finishes turning to a new number and set the trip to zero. Drive the bike until the odometer just turns an additional "10 miles". You will find that the trip reads just over 12.4 miles or exactly 20KM. " All that said- Guzzi has been known to make 'parts bin' bikes out of whatever is left over. In that case, the bike may have parts from several year models. This can be frustrating, but it attests to the fact that most parts from one year will fit on other year models. Decoding the VIN number (thanks to Todd Haven of MPH Cycles) Z is for Italy GU is for Guzzi KRAKR designates 1100 spine frame 2000-2002(sport and Lemans) 9th digit is undefined 10th digit is model year(not production) W-98, X=99,Y=2000,1=2001,2=2002 11-16th digits are identifying serial number for your specific bike. 4 2 Link to comment Share on other sites More sharing options...
Admin Jaap Posted January 21, 2007 Share Posted January 21, 2007 1999-2001 V11 Sport - Short (Red) Frame models/ original Short Tank: Rosso Mandello - Limited edition, total 600 made, first 300 numbered. (short tank with short frame, but black) --------------------------------------------------------------------------------------------------------------------------------- 2002 (braced, black Long Frame/ Short Tank with chin pad and external pump and filter. Rear rim width changed from 4.5" to 5.5") Le Mans Scura (Öhlins forks, 43mm) Tenni - Limited edition, 170 numbered. Sport Naked (Some of these 2002 Sport Naked were sold as 2003 "carry-over"/ transition models clearly identified by the "chin pad" tank and white face Veglia instruments, and no front crossover exhaust pipe, in three tank colors) "2003" V11 Playboy EE (Exclusive Edition) Pictured with Playmate Tanya Dexters at the early 2003 Brussels Salon. A "carry-over" 2002 with early fuel tank configuration and Veglia instruments. Was there ever more than one bike made? Does anyone know where she is now? [Ahem, the V11 EE, not the playmate! ] ----------------------------------------------------------------------------------------------------------------------------------------- 2003-2004/2005 (Long Frame with long tank, internal pump/filter and no chin pad. Black face ITI / hUR instruments without the earlier angle drives for the speedometer drive cable). Front cross-over pipe, change from 40mm Marzocchi forks to 43mm: Le Mans Ballabio Café Sport Coppa Italia Nero Corsa Rosso Corsa ----------------------------------------------------------------------------------------------------------------------------------- 2005 Scura R 3 2 Link to comment Share on other sites More sharing options...
docc Posted December 16, 2020 Share Posted December 16, 2020 Updated, restored and added images. Original post edited to reflect more current discoveries and understanding. I hope @jrt approves! 2 2 Link to comment Share on other sites More sharing options...
docc Posted January 7, 2021 Share Posted January 7, 2021 I want to thank @jrt for originating this thread. It has been a solid reference over all this time. I've seen other web pages attempting to chronicle the V11 series, but none have the quality and accuracy devoted to this one. 3 Link to comment Share on other sites More sharing options...
docc Posted January 8, 2021 Share Posted January 8, 2021 I see I have also taken some liberties with @Admin Jaap's pictorial post, adding some commentary and trying to refine the transitions. I hope this is okay. I don't want to rub our Chief Whip the wrong way! It occurs to me to mention that, although not pictured, there were V11 "Sport" or "Naked" produced through the end of the range with fork mounted headlamp/instruments just like the early Sport. For the differences in the frames and tanks also see: 1 2 Link to comment Share on other sites More sharing options...
Admin Jaap Posted January 8, 2021 Share Posted January 8, 2021 Docc, once again you have proved your indispensability to this forum! 1 1 Link to comment Share on other sites More sharing options...
docc Posted January 9 Share Posted January 9 Cross-link to @Admin Jaap's gallery of factory images . . . https://www.v11lemans.com/forums/gallery/album/25-factory-pics/ Link to comment Share on other sites More sharing options...
